What is JavaFX?

JavaFX is a set of graphics and media APIs that enables developers to create feature-rich desktop applications. Key features include:

Feature	Description
Hardware-accelerated graphics	Uses GPU for smooth rendering
CSS styling	Style UI with familiar CSS syntax
FXML	Declarative XML-based UI markup
Rich controls library	Tables, trees, web views, charts
Media support	Audio and video playback
2D/3D graphics	Built-in shapes and 3D transformations
Animation API	Smooth timeline-based animations

Diagram of JavaFX architecture: Stage, Scene, layout panes, controls, and CSS styling — **JavaFX:** Stage = window; Scene = content; layout panes arrange nodes; style with CSS.

Setup and Installation

JDK Compatibility

Java 8: JavaFX is bundled with the JDK
Java 11+: JavaFX must be added separately (removed from JDK)

Maven Configuration (Java 11+)

Add these dependencies to your pom.xml:

pom.xml

<dependency>
    <groupId>org.openjfx</groupId>
    <artifactId>javafx-controls</artifactId>
    <version>21</version>
</dependency>
<dependency>
    <groupId>org.openjfx</groupId>
    <artifactId>javafx-fxml</artifactId>
    <version>21</version>
</dependency>

Gradle Configuration

build.gradle

dependencies {
    implementation 'org.openjfx:javafx-controls:21'
    implementation 'org.openjfx:javafx-fxml:21'
}

IDE Setup (IntelliJ IDEA)

When running, add these VM options:

VM Options

--module-path /path/to/javafx-sdk/lib --add-modules javafx.controls,javafx.fxml

Your First JavaFX Application (Hello World)

HelloWorld.java

import javafx.application.Application;
import javafx.scene.Scene;
import javafx.scene.control.Button;
import javafx.scene.layout.StackPane;
import javafx.stage.Stage;

public class HelloWorld extends Application {

    @Override
    public void start(Stage primaryStage) {
        // Create a button
        Button btn = new Button();
        btn.setText("Say 'Hello World'");

        // Add event handler
        btn.setOnAction(event -> {
            System.out.println("Hello World!");
        });

        // Create layout and add button
        StackPane root = new StackPane();
        root.getChildren().add(btn);

        // Create scene (300x250 pixels)
        Scene scene = new Scene(root, 300, 250);

        // Set up stage and show
        primaryStage.setTitle("Hello World!");
        primaryStage.setScene(scene);
        primaryStage.show();
    }

    public static void main(String[] args) {
        launch(args);  // Entry point
    }
}

To run:

Terminal

javac HelloWorld.java
java HelloWorld

What's happening:

Your class extends Application
The start() method is the main entry point
launch(args) initializes the JavaFX runtime

Core Concepts: Stage, Scene, and Nodes

JavaFX uses a hierarchical structure:

Hierarchy

Stage (Window)
  └── Scene (Container)
       └── Scene Graph (Tree of Nodes)
            ├── Button
            ├── Label
            └── Layout Container
                 └── More Nodes...

Stage (Window)

Stage

Stage stage = new Stage();
stage.setTitle("My Window");
stage.setWidth(400);
stage.setHeight(300);
stage.setResizable(true);
stage.show();

Scene

// Scene with node and size
Button button = new Button("Click Me");
Scene scene = new Scene(button, 400, 300);

// Scene with layout
VBox vbox = new VBox(button);
Scene scene2 = new Scene(vbox, 400, 300);

Node Properties (Common to all UI elements)

Node properties

Button btn = new Button("Submit");
btn.setVisible(true);
btn.setDisable(false);
btn.setOpacity(0.8);
btn.setStyle("-fx-background-color: blue;");

Layouts and UI Controls

Common Layouts

Layout	Description
VBox	Vertical arrangement
HBox	Horizontal arrangement
GridPane	Grid layout (rows and columns)
BorderPane	Top, bottom, left, right, center regions
StackPane	Stacked nodes (one on top of another)

Layout Examples

VBox (Vertical):

VBox

VBox vbox = new VBox(10); // 10px spacing
vbox.getChildren().addAll(
    new Label("Username:"),
    new TextField(),
    new Label("Password:"),
    new PasswordField(),
    new Button("Login")
);

GridPane (Form layout):

GridPane

GridPane grid = new GridPane();
grid.setHgap(10);
grid.setVgap(10);

grid.add(new Label("Name:"), 0, 0);
grid.add(new TextField(), 1, 0);
grid.add(new Label("Email:"), 0, 1);
grid.add(new TextField(), 1, 1);

BorderPane (Main layout):

BorderPane

BorderPane border = new BorderPane();
border.setTop(new Label("Header"));
border.setCenter(new TextArea("Main content"));
border.setBottom(new HBox(new Button("OK"), new Button("Cancel")));

Common UI Controls

UI Controls

// Basic controls
Label label = new Label("Enter data:");
TextField textField = new TextField();
PasswordField pwdField = new PasswordField();
Button button = new Button("Submit");
CheckBox checkbox = new CheckBox("Accept terms");
RadioButton radio = new RadioButton("Option 1");

// Selection controls
ComboBox<String> combo = new ComboBox<>();
combo.getItems().addAll("Option A", "Option B", "Option C");

// ListView
ListView<String> listView = new ListView<>();
listView.getItems().addAll("Item 1", "Item 2", "Item 3");

// TableView
TableView<Person> tableView = new TableView<>();

Event Handling

JavaFX uses a functional event handling model.

Button Click Event

Button events

Button btn = new Button("Click Me");

// Lambda expression (modern approach)
btn.setOnAction(event -> {
    System.out.println("Button clicked!");
});

// Method reference
btn.setOnAction(this::handleButtonClick);

Mouse Events

Mouse events

btn.setOnMouseEntered(event -> {
    btn.setStyle("-fx-background-color: lightblue;");
});

btn.setOnMouseExited(event -> {
    btn.setStyle("-fx-background-color: lightgray;");
});

btn.setOnMouseClicked(event -> {
    if (event.getClickCount() == 2) {
        System.out.println("Double-click detected!");
    }
});

Keyboard Events

Keyboard events

Scene scene = new Scene(root, 400, 300);
scene.setOnKeyPressed(event -> {
    switch (event.getCode()) {
        case ENTER:
            System.out.println("Enter pressed");
            break;
        case ESCAPE:
            System.out.println("Escape pressed");
            break;
        default:
            break;
    }
});

TextField Events

TextField listener

TextField tf = new TextField();
tf.textProperty().addListener((observable, oldValue, newValue) -> {
    System.out.println("Text changed from '" + oldValue + "' to '" + newValue + "'");
});

CSS Styling

JavaFX uses CSS-like syntax prefixed with -fx-.

Inline Styling

Inline CSS

Button btn = new Button("Styled Button");
btn.setStyle(
    "-fx-background-color: #4CAF50; " +
    "-fx-text-fill: white; " +
    "-fx-font-size: 14px; " +
    "-fx-padding: 10px 20px;"
);

External CSS File (style.css)

style.css

/* style.css */
.root {
    -fx-font-family: "Segoe UI";
    -fx-base: #f0f0f0;
}

.button {
    -fx-background-color: linear-gradient(to bottom, #4CAF50, #45a049);
    -fx-text-fill: white;
    -fx-font-size: 14px;
    -fx-padding: 10px 20px;
    -fx-background-radius: 5px;
}

.button:hover {
    -fx-background-color: linear-gradient(to bottom, #45a049, #3e8e41);
    -fx-cursor: hand;
}

.button:pressed {
    -fx-background-color: #3e8e41;
}

.label {
    -fx-font-size: 12px;
    -fx-text-fill: #333333;
}

.text-field {
    -fx-padding: 8px;
    -fx-border-color: #cccccc;
    -fx-border-radius: 4px;
}

.text-field:focused {
    -fx-border-color: #4CAF50;
}

Loading CSS

Load CSS

Scene scene = new Scene(root, 600, 400);
scene.getStylesheets().add(getClass().getResource("style.css").toExternalForm());
// or
scene.getStylesheets().add("file:///path/to/style.css");

FXML (Declarative UI)

FXML separates UI layout from application logic using XML.

FXML File (login.fxml)

login.fxml

<?xml version="1.0" encoding="UTF-8"?>
<?import javafx.scene.layout.VBox?>
<?import javafx.scene.control.Label?>
<?import javafx.scene.control.TextField?>
<?import javafx.scene.control.PasswordField?>
<?import javafx.scene.control.Button?>

<VBox xmlns="http://javafx.com/javafx/21"
      xmlns:fx="http://javafx.com/fxml/1"
      fx:controller="LoginController"
      spacing="10" alignment="CENTER"
      style="-fx-padding: 20;">

    <Label text="Login Form" style="-fx-font-size: 20px;"/>
    <TextField fx:id="usernameField" promptText="Username"/>
    <PasswordField fx:id="passwordField" promptText="Password"/>
    <Button text="Login" onAction="#handleLogin"/>
    <Label fx:id="messageLabel" style="-fx-text-fill: red;"/>

</VBox>

Controller Class (LoginController.java)

LoginController.java

import javafx.fxml.FXML;
import javafx.scene.control.Label;
import javafx.scene.control.PasswordField;
import javafx.scene.control.TextField;

public class LoginController {

    @FXML
    private TextField usernameField;

    @FXML
    private PasswordField passwordField;

    @FXML
    private Label messageLabel;

    @FXML
    private void handleLogin() {
        String username = usernameField.getText();
        String password = passwordField.getText();

        if ("admin".equals(username) && "secret".equals(password)) {
            messageLabel.setStyle("-fx-text-fill: green;");
            messageLabel.setText("Login successful!");
        } else {
            messageLabel.setStyle("-fx-text-fill: red;");
            messageLabel.setText("Invalid credentials!");
        }
    }
}

Loading FXML in Main Application

MainApp.java

import javafx.application.Application;
import javafx.fxml.FXMLLoader;
import javafx.scene.Parent;
import javafx.scene.Scene;
import javafx.stage.Stage;

public class MainApp extends Application {

    @Override
    public void start(Stage primaryStage) throws Exception {
        Parent root = FXMLLoader.load(getClass().getResource("login.fxml"));
        primaryStage.setTitle("Login Application");
        primaryStage.setScene(new Scene(root, 300, 250));
        primaryStage.show();
    }

    public static void main(String[] args) {
        launch(args);
    }
}

Animation and Effects

Transitions (Built-in Animations)

Transitions

import javafx.animation.*;
import javafx.util.Duration;

Button btn = new Button("Animate Me");

// Fade transition
FadeTransition fade = new FadeTransition(Duration.seconds(2), btn);
fade.setFromValue(1.0);
fade.setToValue(0.3);
fade.setCycleCount(Animation.INDEFINITE);
fade.setAutoReverse(true);
fade.play();

// Translate (move) transition
TranslateTransition translate = new TranslateTransition(Duration.seconds(1), btn);
translate.setByX(100);
translate.setByY(50);
translate.setCycleCount(2);
translate.setAutoReverse(true);
translate.play();

// Rotate transition
RotateTransition rotate = new RotateTransition(Duration.seconds(2), btn);
rotate.setByAngle(360);
rotate.setCycleCount(Animation.INDEFINITE);
rotate.play();

// Scale transition
ScaleTransition scale = new ScaleTransition(Duration.seconds(1), btn);
scale.setToX(1.5);
scale.setToY(1.5);
scale.setAutoReverse(true);
scale.setCycleCount(Animation.INDEFINITE);
scale.play();

Timeline (Custom Animations)

Timeline

Timeline timeline = new Timeline();
KeyFrame keyFrame = new KeyFrame(
    Duration.seconds(2),
    event -> System.out.println("2 seconds passed!")
);
timeline.getKeyFrames().add(keyFrame);
timeline.setCycleCount(3);
timeline.play();

Visual Effects

Effects

import javafx.scene.effect.*;

Button btn = new Button("Effect Button");

// Drop shadow
DropShadow dropShadow = new DropShadow();
dropShadow.setRadius(5.0);
dropShadow.setOffsetX(3.0);
dropShadow.setOffsetY(3.0);
btn.setEffect(dropShadow);

// Gaussian blur
GaussianBlur blur = new GaussianBlur();
blur.setRadius(5);
btn.setEffect(blur);

// Reflection
Reflection reflection = new Reflection();
reflection.setFraction(0.7);
btn.setEffect(reflection);

Working with Command Line Arguments

JavaFX applications can access command-line arguments through the Application.Parameters class.

Parameters example

import javafx.application.Application;
import javafx.stage.Stage;
import java.util.List;

public class ArgsApp extends Application {
    @Override
    public void start(Stage stage) {
        List<String> params = getParameters().getRaw();
        List<String> unnamed = getParameters().getUnnamed();
        System.out.println("Raw parameters: " + params);
        System.out.println("Unnamed arguments: " + unnamed);
    }

    public static void main(String[] args) {
        launch(args);
    }
}

Run with named and unnamed parameters:

Terminal

java ArgsApp --mode=debug input.txt output.txt

Summary and Best Practices

Best Practice	Reason
Use `Platform.runLater()` for UI updates from threads	Prevents threading errors
Separate UI from logic with FXML	Easier maintenance and testing
Use CSS for styling	Consistent look across application
Bind properties rather than manually updating	Reduces boilerplate code
Handle stage close events	Clean up resources
Follow MVC/MVP patterns	Better code organization
